Đếm tốc độ động cơ, đếm xung tốc độ cao bằng encoder ELCO và PLC Siemens S7-300.

Encoder ELCO - Bo dem xung

• Ứng dụng chung của encoder: trong các bài toán đo tốc độ và feedback tín hiệu về điều khiển động cơ,

• Cấu tạo chính của Encoder: gồm 1 bộ thu và phát ánh sáng, 1 hay 2 đĩa quang gắn trên trục quay đặt giữa bộ phát và thu, trục quay này sẻ được gắn vào trục động cơ cần xác định tốc độ

[youtube https://www.youtube.com/watch?v=WCH0siLAwRY]

• Nguyên lý cơ bản: trên đĩa quang có khoét nhiều lổ cho phép ánh sáng truyền qua theo các cách mã hoá khác nhau, số lổ này sẻ quyết định độ chính xác của thiết bị đo. Ví dụ đĩa quang của bạn có 1 lổ tức là khi bạn quay được 1 vòng thì bộ thu sẻ thu được 1 xung, nếu đĩa quang của bạn khoét N lổ có nghĩa 1 vòng bạn thu được N xung. Như vậy khi đo tốc độ bạn đếm số xung trong 1 đơn vị thời gian, từ đó bạn tính được số vòng trên 1 đơn vị thời gian.Nếu đo tốc độ cao thì số lổ khoét càng nhiều càng chính xác.

• Truyền thông Profibus giữa PLC Siemens CPU 314C-2DP và encoder ELCO Bộ chia tín hiệu của encoder rất tiện dụng được ứng dụng chia thành nhiều tín hiệu mục đích có thể một tín hiệu đưa về biến tần tín hiệu còn lại đưa về PLC hoặc tùy ứng dụng của bạn. video này mình hướng dẫn đếm xung và đếm số vòng quay của động cơ.
